Thor's Lightning SNR G150.3+4.5, Barn 8, LDN 1400



MOUSE-OVER IMAGE FOR STARLESS VIEW

CLICK ON IMAGE FOR FULL SIZE VIEW (5773x4176)

Scope: AT60EDP at f/5, Location: DAA Observatory, Shelter Valley, CA; Dates:   3, 4 December, 2024;  Camera: ASI2600MM (Astronomik type 2c LRGB, 6 nm Ha and OIII filters)

Exposure: Exposure: Ha - 63 x 5 min (gain-180 1x1),  OIII - 62 x 5 min (gain-180 1x1), Lum - 72 x 3.5 min (gain-101 1x1), RGB - 36 x 2 min (gain-101 1x1) each RGB exposures.

Processing: Data Collection -  N.I.N.A. Sequencer (as FITs).  Sub-frame calibration - Pixinsight (WBPP). Sub-frame  registration and integration (Average combine -   linear fit clipping) - PixInsight (WBPP).    Noise reduction - NoiseXTerminator - PixInsight. Non-linear stretching, normalization and gradient removal - PixInsight. Photometric RGB calibration (SPCC) - PixInsight. Deconvolution of  Lum, Ha, OIII, and RGB stacks (RGB combine) - BlurXTerminator. Generation of starless nebulosity Lum, Ha, OIII , and RGB images for later processing - StarXTerminator.  Curves, Levels, RGB combine - PixInsight.  RGB Stars and starless  combine - PixInsight.   Final finishing  - Affinity Photo.   Annotation - PixInsight, Aladin (Simbad ), and Affinity Photo. This image is a  modified HOO Narrow Band  and screened LRGB starless construction - with RGB stars added.  Image processed at 6248x4176 resolution. Final Image size is approximately  5773x4176.

"Thor's Lightning" is the collection of blue features seen in the image. They are part of a Supernova shell and are OIII emission caused by the expanding energy from the supernova event. The shell distance estimates range from 2,280 to 14,670 light years. The supernova event is estimated to have occurred 38 thousand to 160 thousand years ago. The large red feature is a Hydrogen-Alpha emission as recorded through the Ha exposures. Interestingly enough, there doesn't seem to be any astronomical identification or designation for it. The dark and smoky looking features running generally from upper left to lower right are dark nebulae caused by the obstruction of interstellar material.

This interstellar material lane has been extensively cataloged by Lynds and by Barnard. The LDN objects (LDN 1392 .. 1394, 1396 .. 4014) run from left to right - as do the Barnard objects (Barn 8, 9, 11, 12, 13, 21).  Also  there are a few small galaxies seen in the lower portion of the image. They are visually small since their distances range from 205 to 234 million light years.

 These objects and some of the brighter stars are identified in the annotated image

Horizontal FOV is approximately 4.14 degrees. Full size image scale is about 2.58 arcsec/pix. North is at 164 degrees (about 16 degrees shor of a full 180 degree north down orientation).

Image center is approximately - Equatorial 2000: RA: 04h 26m 48s Dec: +55°11'04"
