Sharpless 235 in Auriga
Archives




CLICK ON IMAGE FOR FULL SIZE VIEW

Scope: C8 203mm  at f/4.8,  Location: Blair Valley, Anza Borrego Desert, CA  3 November,  2007,   Camera: Artemis285

Exposure: 8 x 7 min H-Alpha (1x1), 8 x 1.5 min RGB Exposures (2x2).

Processing: Images were captured  with Artemis Capture (as FITs).  Aligned/stacked and dark subtracted in Astroart with Sigma Combine.   H-Alpha  and Color channels were scaled and  color balanced in Astroart.  Channels were co-registered in Astroart.  Luminance construction consisted of the H-Alpha exposure.  Curves and Levels applied in Photoshop to the Luminance construction to optimize object features.  Final LRGB combine was done in Photoshop using Luminance Layering in LAB color Space. A color adjustment made to correct the color at low RGB signal levels.  A light background noise reduction was applied in PixInsight LE (SBNR)  Selective sharpening was applied to nebula features in Photoshop with a layer mask.  Final Image size is approximately 1040x1392

 North is up in this image. The field in this image is from the constellation of Auriga. Sharpless 235 is an  emission nebula in this image. The Horizontal FOV is 32'.

Image center is located approximately - Equatorial 2000: RA: 05h 40m 48.0s Dec: +35°43'12"
