M17 Omega Nebula


Scope: C8 f/2.8; Location: Laguna Mountains, CA; 10 Jul. 2004; Camera: ToUcam SC3

Exposure: 16 x 60 sec and 16 x 20 sec Luminance exposures with Baader IR Block Filter; 12 x 32 sec RGB

Processing: Images were captured in K3CCDTools. Aligned/stacked in Registax and saved as FITS. Luminance and Color channels were scaled and rough color balanced in Astroart. Channels were co-registered in Astroart. Shorter Luminance exposure was normal combined in Photoshop with mask to the longer one to reduce star bloat and to desaturate the bright parts of the nebula. Luminance and Color FITS were combined in Photoshop with Luminance Layering. Color balancing and final touches in Photoshop. SGBNR was used to smooth background noise on the luminance channel and the final result.

This image was taken with fairly good conditions at a dark site. This is a guided image. This is the so called Omega Nebula. The dark site conditions allowed me to do this image without any Narrow band filter (H-Alpha). Horizontal FOV is 31'
