NGC 5907 in Draco



CLICK ON IMAGE FOR FULL SIZE VIEW

Scope: C8 f/6.4; Location: Blair Valley, Anza Borrego, CA;  27 March 2009; Camera: Artemis285

Exposure: 10 x 6 min Luminance exposure (bin 1x1) with IR/UV Block Filter; 7 x 3 min RGB (bin 2x2)

Processing: Images were captured Artemis Capture (as FITs). Aligned/stacked and dark subtracted in Astroart with Sigma Combine. Luminance and Color channels were scaled and rough color balanced in Astroart. All combined stacks were up-sampled to 1392x1040 (1x1 bin resolution). Central Gradient was removed on all channels in Astroart. Channels were co-registered in Astroart. The 6 minute IR block exposures were used for the main luminance construction with level adjustments and curves to bring out object features.   LRGB combine was done in Photoshop. G2V  factors applied to color channels.  Background noise reduction was done with a blurred background layer set on a lighten blend .  Selective sharpening was applied to galaxy features. Final Image size is approximately 1392x1040.

This image was guided; North is to the Right.  This galaxy, NGC5907 is mostly edge on from Earth's perspective. It is located in the constellation of  Draco. Ii is sometimes known by the common name of the Splinter Galaxy or the Knife Edge Galaxy. Its distant from Earth is estimated at about 40 million light years.  Horizontal FOV is 23'.

Image Center is approximately - Equatorial 2000: RA: 15h 15m 54s Dec: +56°19'00"
